Range feeder, top right, holds 300 lbs. feed. The 36” diameter shield sits low over feed pan to keep feed dry. Shield is held in place with silicon sealant. The lid, with built-in locks to keep it from being blown off, is peaked to prevent birds from perching. Feeders ship at 80 lbs. & 81 lbs. DW + $8.50 special handling. The following products are drop-shipped from the Kuhl Corp.

RF300-P    Kuhl Pheasant Poly Range Feeder

$208.00

QF 300-P  Kuhl Quail Poly Range Feeder

$208.00

RF300 L-P Either feeder without shield

$162.00

SHIELD    Replacement shield only

$81.00

D-PAN 4 1/2” Replacement pan only

$59.00

Q-PAN 3 1/2” Replacement pan for quail only

$59.00

R-LID Replacement lid only

$36.00

RFEXT   Range feeder tube extension only

$68.00

Feeders are poly construction with stainless steel hardware. Feeder has overlapping parts to make all seams waterproof.  Low, wide rain shield reduces the amount of rain that can blow into the pan. Large pan circumference (approximately 40”) provides more feeding space for birds, reducing the number of  feeders per pen.  Narrow stepped pan design reduces the  amount of fines that can build up in the pan.  Mold build up is prevented by 6 unique  support legs that do not allow feed to block up  behind them. Feed flow adjusts from 1 ¼ ” to 3 ¼ ”.  45° cone ensures adequate feed flow into the pan.  Easy to open/close lid can adapt to fit an automatic feed line.  27 ½ ” wide opening allows for filling either by hand or with an auger T1000K is 24 “ tall without the lid.  Can be ordered with either a Chukar or pheasant pan. T1000J is 40” tall without lid.  Feeders are shipped by truck.  Call for shipping quote. Price does not include skides.

T1000K 450 Pound Range Feeder

$255.00

T1000J  900 Pound Range Feeder

$375.00

Brower range feeder, is 36” h. Pan is 3¾” deep & 29” in diameter. Cover has built-in hand-hold for easy removal.    8” adjustable shield keeps feed dry. Made of durable poly heavy-duty material. Holds 175 lbs. of feed. Holds 305 lbs of feed with feeder extension. Feeders are drop-shipped from Iowa. Call for shipping quote.

GBF-175*  Game Bird Feeder 2 ctns ea 86 lbs. DW

$210.00

GBFQ-175*  Quail Feeder   2 ctns ea  86 lbs. DW

$210.00

2 GBF-175* or 2 GBFQ-175* Feeders  2 ctns. DW

$400.00

6 GBF-175* or 6 GBFQ-175* Feeders  275 lbs.

$1100.00

QBF1515*   Galvanized Feeder Extension

$66.00

CQB1520*   Poly Feeder Extension

$66.00

JABF800 800-pound Range Feeder

$550.00

The feed pan of the JABF800 has a circumference of 148 inches providing 148 linear inches of feeding space which is enough  for up to 250 pheasants. The pan has a 13 inch(33 cm) cone in the bottom to provide good cleanout.  The upper body projects out over the lower body so that there is a natural taper to facilitate feed flow. There are no ledges or gaps to catch and retain stale feed. The feed level can be determined through the translucent side wall material. The rain shield is molded into the upper body assuring water tightness. No caulking is needed to prevent leaks. The rain shield extends beyond the trough 6 inches(15.2 cm). The height of the rain shield above the trough is about 11 inches(28 cm). The heavy-duty cone-shaped cover prevents roosting. Cover slides back and is retained in place with a cable design. The body attaches to the trough with 12 galvanized steel 13 gauge legs. Each leg has 10 holes with ½ inch (1.3 cm) spacing allowing an adjustable feed opening. Feeder is constructed of heavy duty polyethylene material with hindered amine light stabilizer, the most potent ultraviolet protection. The wall thickness is at least .2 inch which is up to 3 times the thickness of competing feeders in critical areas. Ships by truck.  Call for a shipping quote.

RF50**    50-lb. range feeder with rain shield is 24” h. Pan is 4¾” d with a 22 ½” diameter. The RF50 has feed saver grill.1 or 2 feeders will ship at 86 lbs. DW.  6 RF50 ship in two 86 lb. pkg.     Drop shipped from Kuhl Corp.

$79.00

RF50-2**

Carton of 2 50-lb. range feeders

$152.00

RF50-6**

Carton of 6 50-lb. range feeders

$435.00

CR-50**

Ctn. of 2 50-lb. Chukar range feeders (no feed saver grill)

$158.00

QR-50**

Ctn. of 2 50-lb. Quail range feeders

(middle right) does not have a feed saver grill

$158.00

HF-50-2**

Carton of 2 50-lb. feeder with lids. Feeder (bottom right) is app. 22” high, the pan is 4¾” deep with a 22 ½” diameter. The RF50 has feed saver grill. Use inside buildings or shelters when large quantities of feed are needed    Drop-shipped from mfg. 56 lbs. DW

$51.00

HF50-6**

Ctn of 6 feeders with lids  ships at 86 lbs. DW

$141.00

Galvanized & Plastic Hanging Feeders

MHF1 Plastic hanging feeder (top right) is 7½” h x 8¼” in diameter.  Holds 3½ pints of feed.

$4.00

3/11.25

MHF3 Plastic hanging feeder with cone lid (below MHF1) is 12¼” h; pan is 12” in diameter. Holds app. 12 lbs.

$13.50

3/$39.00

BHF15 Brower plastic hanging feeder (center right)  The an is 1 ⅞” deep with a 12” diameter. Non-adjustable feed flow. Use with chicks up to 6 wks old, quail, or smaller fowl.

$12.50

3/$36.00

BHF30 Brower plastic hanging feeder has a wire snap adjustment permits feed opening of 3/8”, 3/4”, or 1 3/8”. 16 1/2” diameter pan is 3” deep. BHF 15 & 30 contain ultraviolet inhibitors.

$17.00

3/$48.00

C6P Feed cover lid has a hole in the center for using with a feeder with a center adjustment rod such as the HF20G or it can be over the handle as shown in picture below the BHF30 feeder.

$1.75

R-30-3  Plastic 18” h. feeder has a hinged lid.  Use feeder with baby chicks, adult quail, or even poultry.  A control in the center of the feeder adjusts to  raise or lower the feed tube. This regulates the height of the feed in the pan to save feed.  The pan is 1 ½” h with a 20 ½” diameter. Carton of 3 R30 feeders is drop-

shipped. (wt. 30 lbs. DW *)

$48.00*

HF20G Kuhl plastic hanging feeder has an inward rolled lip to save feed. The feed pan is 17¼” in diam., 2¾” d, & Tube has molded grill & holds app. 25 -30 lbs. DW 34 lbs. 2 feeders; DW 86 lbs. 6 feeders

2/$40.00*

6/$95.00*

GLV12H Brower galvanized feeder holds 12 lbs. feed. Is 10” h. Pan is 2 ½” d & 11½” in diameter.

$12.50

3/$36.00

GLV30H Brower galvanized feeder holds 30 lbs. feed. Is 15” h. Pan is 2 ½” d & 14” in diameter.

$17.00

3/$48.00
